Fasco D429 Motor | 9 Watt 1550 RPM CCW 115 Volts Unit Bearing Motor

• 9 Watt 1550 RPM, .6 Amps, 115 Volts 60 hz.
• Shaft Threaed-Hub Mount
• Stud Mount – Bolt Circle – 2.84″
• 3 mounting studs opposite shaft end
• Motor Length Less Shaft = 3″
• 22″ leads
• Sleeve bearings
• 1 Year Manufacture Warranty.

Application Information: Condenser Fan, Cooler: Evaporative, Cooler: Walk-In, Display Case: Refrigerated. These motors often replace unit bearing motors whose rotation is described opposite shaft end. This is different from the Fasco standard, which is determined by looking at shaft end. Three Studs opposite shaft end are 8-32 on a standard 2.84″ bolt circle. 120 degrees apart. Cross Reference GE # 5411
