C1460 Marathon 3/4 Hp 115/230V 1800 RPM ODP 56 Frame Instant Reversiing Motor

• 3/4 hp 1800 RPM, 13.2/6.6 amps, 115/230 Volts 60 Hz, Capacitor Start
• NEMA 56 Frame, Shaft 1 7/8″ x 5/8″ Diameter, 1 speed
• Service Factor = 1.25, Thermal Protection = None
• Rigid Base, Reversible rotation, Ball Bearings, Class B insulation
• 1 Year Manufacture Warranty

For applications requiring fast motor reversals. Shaft should be horizontal. ODP = Open Drip Proof. 5KC46LN0252
