Bison 021-746-9030 Right Angle Gear Motor 1/15 Hp 59 RPM Hp 90V DC
Original price was: $349.00.$96.99Current price is: $96.99.
- The best quality products, always.
- Best price, safe shopping guarantee
- Protect Your Information, Shop with Safe Payments
- Safe Shopping Guaranteed
- 746 Series DC Right Angle Gear Motor – Subject to factory availability-email or call for availability
- Torque 41 inch pounds; Over Hung lbs. = 224
- Rotation = Reversible
- 1/15 hp 59 RPM, .8 amps, 90 Volts DC
- TEFC Enclosure, Keyed Shaft, Ball Bearings
Optional Accessories: P198-100-9111 Junction Box, P125-746-0500 Mounting Foot Plate. P158-200-2600, Replacement Brush Set # P158-200-2600. Permanent Magnet motor, Insulation Class B; Finish: Powder-coat gloss black; Brushes: Replaceable; Gearhead Specifications: Housing – Precision machined die cast aluminum; Shafts – Hardened steel; Gearing: Hardened Steel worm. Forged bronze gear; Lubrication: Lifetime oil bath, sealed and gasketed; Any angle mount; Bearings – Ball and Needle Bearings. Suggested replacement reference for: Baldor GP233005. Can use with Leeson speed control 174307, 174308.
